Description
BLOX Racing camshafts are designed and manufactured using OEM-spec, chill-cast camshaft cores.BLOX Racing manufactures camshaft cores specifically tailored to the D16Z6 and D16Y8 engines. MAY BE USED WITH Z6 WHEN USING BLOX CAM GEAR
Stage 1 Camshafts:
Ideal for stock to mild engine builds.
Upgraded valvetrain is not necessary but is always recommended.
Stage 2 Camshafts:
Ideal for mild to highly modified engine builds.
Upgraded valvetrain is required. Head porting is HIGHLY recommended.
Stage 3 Camshafts:
Ideal for highly modified to full race engine builds.
Upgraded valvetrain, cylinder head machining + porting, high compression pistons, and ECU tuning are ALL required.
Stage 1 Cam Specs @ 0.050″
- INTAKE: 232 / 0.253″ (Gross lift: 0.405″)
- EXHAUST: 211 / 0.213″ (Gross lift: 0.383″)
Stage 2 Cam Specs @ 0.050″
- INTAKE: 242 / 0.268″ (Gross lift: 0.429″)
- EXHAUST: 218 / 0.242″ (Gross lift: 0.436″)
Stage 3 Cam Specs @ 0.050″
- INTAKE: 247 / 0.276″ (Gross lift: 0.442″)
- EXHAUST: 230 / 0.255″ (Gross lift: 0.459″)
Features:
- High quality at an affordable price
- Expertly made from premium materials
- Built to match your exact requirements
Specification
- Category: Camshafts
- Fitment Spec: Vehicle Specific
- MPN: BXCM-20101-Z4
- Part Type: Camshafts
