Description
Product information
| Weight | 10.98 lbs |
|---|---|
| Dimensions | 24.55 × 3.2 × 2.75 in |
| Product Line |
Xtreme Energy |
| Camshaft Lifter Style |
Hydraulic Roller Tappet |
| Advertised Intake Duration |
266.0 |
| Intake Duration At 0.050 In |
216.0 |
| Advertised Exhaust Duration |
274.0 |
| Exhaust Duration At 0.050 In |
224.0 |
| Intake Lift |
0.544 in |
| Exhaust Lift |
0.555 in |
| Lobe Separation Angle |
112 Degrees |
| Operating Range Rpm Lower |
1600 RPM |
| Operating Range Rpm Upper |
5600 RPM |
| Manufacturer Grind Number |
XE266HR |
| Material |
Billet Steel |
| Color |
Natural |
| Finish |
Natural |
| Quantity |
Each |
| Note |
Hydraulic Roller – Xtreme Energy Computer Controlled: Mild modifications, 3.27-3.73 gear, mass air, larger throttle body. |
| UPC Code |
36584031567 |
| Brand |
COMP CAMS |
| Type |
Camshafts |
| Condition |
New |
| Manufacturer Part Number (MPN) |
35-514-8 |
Description Camshaft – Xtreme Energy – Hydraulic Roller – Lift 0.544 / 0.555 in – Duration 266 / 274 – 112 LSA – 1600 / 5600 RPM – Small Block Ford – Each Features
