Description
Product information
| Weight | 14.95 lbs |
|---|---|
| Dimensions | 28.5 × 12 × 5 in |
| Product Line |
400 Series Dome |
| Bore |
4.155 in |
| Style |
Dome |
| Material Style |
Forged |
| Compression Height |
1.260 in |
| Volume |
Plus 9.00 cc |
| Wrist Pin Included |
Yes |
| Wrist Pin Style |
Floating/Press |
| Wrist Pin Diameter |
0.927 in |
| Wrist Pin Length |
2.750 in |
| Piston Weight |
485 g |
| Top Ring Groove Thickness |
1/16 in |
| 2Nd Ring Groove Thickness |
1/16 in |
| Oil Ring Groove Thickness |
3/16 in |
| Oil Support Rail Included |
Yes |
| Alloy |
2618 |
| Material |
Aluminum |
| Finish |
Natural |
| Quantity |
Set of 8 |
| Variant |
Yes |
| Variant Group |
Pistons246 |
| Variant Column |
Bore |
| Valve Angle |
23 Degree |
| UPC Code |
193564249180 |
| Brand |
SPORTSMAN RACING PRODUCTS |
| Condition |
New |
| Type |
Pistons |
| Manufacturer Part Number |
142034 |
Description Piston – 400 Dome – Forged – 4.155 in Bore – 1/16 x 1/16 x 3/16 in Ring Grooves – Plus 9.00 cc – Small Block Chevy – Set of 8 Features
